ORDERING INFORMATION CADDX PART # DESCRIPTION NX-8 KIT Includes NX-8 Control, NX-108 LED Keypad, & 16.5V 25VA Transformer NX-8 NX-8 Control Only NX-108 8 Zone LED Keypad NX-116 16 Zone LED Keypad NX-124 24 Zone LED Keypad NX-148 Alphanumeric LCD Keypad NX-200. Zone Doubling Kit (Includes 100 3.74k and 100 6.98k resistors). The wiring should be correct. With the motion cover in place, and no motion activating the detector, if you use a meter at the mother board end (take them off the terminals), you should see the resistor value. If someone walks in front of the motion, you should see an open. If so, then your wiring is correct, and you may have a programming issue.

CaddxHi Mike,

Do you want to do a 'factory default' on the NX-8 panel? If that is what
you want to do, click the following link for the manual. Go to page 8 and
follow the instructions for 'Loading Factory Defaults' in the center of the
page.

NOTE: Doing this will clear the program, requiring you to program the entire
system from scratch. Please be absolutely certain this is what you want to
do before doing so.

Networx

If all you want is to change the Download Access Code, that is stored in
Location 20. Follow the instructions for changing that value alone.

Another significant code is the 'Go To Program' code, found in location 42.
It's a 4- or 6-digit code. This is the code you use to enter programming
mode.

To change any item, enter programming as follows:

Panel

Disarm the system.
Press [*]-[8].
Enter the current 'Go To Program' code.
Press [0]-[#] to program functions of the NX-8 master control panel itself.
Enter the location number you wish to display/alter, followed by the [#]
key.
Enter the desired new data, followed by the [*] key.
After you press the [*] key the program will advance to the next segment.
Change it if needed and press [*] to scroll on.

For more detailed instructions, see page 9 of the manual I referenced above.

Regards,
Robert L Bass

How To Program Caddx Nx 8

>
Bass Home Electronics
The Online DIY Alarm Store
http://www.Bass-Home.com
4883 Fallcrest Circle
Sarasota, FL 34233
877-722-8900 Sales & Tech Support
941-925-9747 voice (Florida)
941-923-6238 fax
Rober...@home.com
>
